Temporizzatore timer 120 minuti monofresato
- Interruttore a 2 vie ad apertura rapida con opzione di accensione non temporizzata (PM)
- Perno Ø 6 x 4,5 mm.
- Lunghezza perno 23,5 mm.
- Portata 16A 250V
- Temporizzazione 120' su 300°
- Attacchi faston 6,3 x 0,8 mm.
- Segnalazione acustica di fine ciclo 3 secondi
- Entrata viti max 2,5 mm. (M4)
- Temperatura d'impiego +125°
PM = Posizione manuale con contatto chiuso,in posizione 0 contatto aperto
Per modelli:
FM22MIX, FC52(IX) 03255220100 , G2 V(W) G1 MC (W) GR G0 ME (W) GR G0 ME (GR) GR FM22 M IX G2 V.E (W) FM22 M (AN) G 650 MC G2 VTD (W) R G1 MC (W) R FM22 M IX AUS.1 FM 52F (WH) FM 52F (BK) G1 MD10 (X) FM 52 R IX PM52 IX(1) PM52 (WH)(1) PM52 (BK)(1) C 648 PT X C 648 B X F ER/60 IX 3I F ER/90 3I F ER/60 IX O1 3I F ER/90 IX 01 3I F KG 904PF IX 2I F KG 904PF CF 2I F BV114PF AL/BL 2I F BV114PF NE/BL 2I F BV114PF AL/BC 2I F BV114PF AL/TR 2I F BV114PF AL/RO 2I F BV114PF AL/GR 2I F BV114PF AL/VR 2I F EX664PF IX 2I F EX665MLF IX 2I F EX664PF BC/IX 2I F EX664PF CF/IX 2I F EX665MLF CF 2I F EX664PF CF/RA 2I F EX664PF BLU/IX 2I F EX664PF VR/RA 2I F EX664PF VR/IX 2I F EX595MLF IX. 2I F EX595MLF CF 2I F EX695MLF IX. 2I F EX695MLF BC 2I F EX695MLF CF 2I F LX804E PF IX 2I F LX804E PF BL 2I F LX804E PF BC 2I F EX664I PF IX 2I F EX665MLFI IX 2I F F665MLF NI IX NI8 2I F EX664I PF BC/IX 2I F EX665MLFI BC/IX 2I F EX664I PF CF/IX 2I F EX665MLFI CF/IX 2I F EX664I PF VR/IX 2I F EX664I PF BLU/IX 2I F F665MLF NI BLU NI9 2I F EX664I PF BC/RA 2I F EX664I PF CF/RA 2I F EX664I PF VR/RA 2I F EX664I PF BLU/RA 2I F EX595MLF IX 2I F EX595MLF CF/IX 2I F EX695MLF IX 2I F EX695EMLF IX ITP1 2I F EX695EMLF IX FMT1 2I F EX695MLF BC/IX 2I F EX695EMLF BC FMT2 2I F EX695MLF CF/IX 2I F EX695EMLF CF FMT3 2I F FT 66 IX. 2I F LX804PF BL 2I F LX804PF BC 2I F LX804PF BC STX2 2I MAG KITC 1200 CF/IX 3I MAG KITC 1600 CF/IX 3I C ERC/90 3I C CTA 630DC/AS BLU 2I C ERC/90 DE 3I C CTA 630DC/AS AVO 2I C ERC/90 BE GN 3I C CTA 630DC/AS IX 2I C CTA 940DC/AS BLU 2I C ERC/90-T 3I C ERC/90-T DE 3I C CTA 940DC/AS AVO 2I C CTA 940DC/AS IX 2I C 658 P (X)T C 615 (W)F F ARC666 BLU 3I F ARC666 BC 3I FM22 M (OG) C 448 M (X) C 648 PT X B FP 666 IX 2I FP 966 IX 2I K 647 VS(W)/O K 647 VSX/O K 600 V(W)/G K 6C7 M(W)/R K 644 M(W)/S K 644 MS(W)/I K 644 MS(X)/I K 642 VS(X)/G K 644 PS(A)/I K 644 PS(G)/I K 644 PS(B)/I C 058 MT (X).1 K 647 PS(X)/I K 642 MS(W)/R F ARC666 .01 BLU 3I F ARC666 .01 BC 3I K 642 V(G)/G C 758 MT (X)/I C 858 MT (X)/I LX 804E2 PF IX 2I LX 804E2 PF BL 2I HGK 2 IX IB. HGM 2 (WH)IB. HGM 2 (BR)IB HGM 2 IX IB/old HPE 2 IX IB. FE 21 (WH)IB. FE 21 (BR)IB. FE 21 IX IB. FM 20 (WH)IB FM 20 (BR)IB FM 20 IX IB. FM 22 M ALU KP 647 VS(X)/O(1) HGK 2 (WH)IB HGK 2 (BR)IB HPE 2 (WH)IB HPE 2 (BR)IB K 345 E(X)/U C 448 M (XA) C 058 MT (XA) C 758 MT (XA)/I K 642R VS(X)/G FO 52 IX FO 52 (ALU) FO 52 (AN) FC 52 IX FC 52 (AN) K 342 MS(W)/I K 342 MS(X)/I LX 804E2 PF MR 2I K 342 V(W)/O K 343 V(X)/O C 68 MT (X) C 68 MT (XA) FO 52 C IX FO 52 C (WH) FO 52 C (BK) FC 52 C IX FC 52 C (AN) FP 966 IX FAV 2I KP 648 VS(X)/O FB 22 AC IX FB 22 AC (WH) HB 22 AC IX HB 22 AC (WH) PB 22 AC IX PB 22 AC (WH) FB 52 C IX FB 52 AC (WH) FB 52 AC (BK) HB 52 C IX HB 52 AC (WH) HB 52 AC (BK) PB 52 C IX PB 52 AC (WH) PB 52 AC (BK) PB 52 A IX PB 52 A (WH) K 6C7 M(W)/SK FC 62 C IX AG K 648 VX/O K 648 V(W)/O K 6C7 M(W)/SV HGK 2 IX IB.. HGM 2 (WH)IB.. HGM 2 IX IB HPE 2 IX IB.. FE 21 (WH)IB.. FE 21 (BR)IB.. FE 21 IX IB.. FM 20 IX IB.. HGK 2 (WH)IB.1.. HGK 2 (BR)IB.1.. HPE 2 (WH)IB.1.. HPE 2 (BR)IB.1.. FB 52 IX AUS FB 52 (WH)AUS FB 82 C IX AUS FB 82 C(WH)AUS HGD 6 IX KP 958 MS(X)/D KP 648 MS(X)/D FD 52 (ICE) FD 52 (MR) CP 648 MT (T) CP 758 MT CP 058 MT K 342 V(W)/IR K 601 V(W)/G K 645 V(X)/G K 645R V(X)/G K 647R V(X)/G FD 52 (CH) FD 52 (SL) FD 52 (GC) CP 6480 MT.2 (X)F FP 653 SCHOLTES FE 21.B (BR) IB FE 21.B (WH) IB FE 21.B IX IB FM 20.B IX IB HGK 2.B (BR) IB HGK 2.B (WH) IB HGK 2.B IX IB HGM 2.B (WH) IB HGM 2.B IX IB HPE 2.B (WH) IB HPE 2.B IX IB FC 52 C.2 /V IX FC 52.2 /V (AN) FC 52.2 /V IX FO 52 C.2 (BK) FO 52 C.2 IX FO 52 C.2 (WH) FO 52.2 (AN) FO 52.2 IX FB 52 C.2 IX FB 52 AC.1 (BK) FB 52 AC.1 (WH) FB 22 AC.1 IX FD 52.2 (CH) FD 52.2 (GC) FD 52.2 (ICE) FD 52.2 (MR) FD 52.2 (SL) PB 52 C.2 IX PB 22 AC.1 IX PB 22 AC.1 (WH) HB 52 C.2 IX HB 52 AC.1 (BK) HB 52 AC.1 (WH) HB 22 AC.1 IX C 658 P.3 (X)T CP 648 MT.2 (T) CP 758 MT.2 (T) CP 058 MT.2 (T) K 644 MS.C (W)/I K 644 MS.C (X)/I K 647 PS.C (X)/I K 648 V.C(W)/O K 648 V.C X/O K 6C7 M.C(W)/R K 6C7 M.C(W)/SV K 6C7 M.C(W)/SK KP 648 MS.B (X)/D KP 958 MS.B(X)/D (T) K 647R V.C(X)/G K 645R V.C(X)/G K 645 V.C(X)/G K 601 V.C(W)/G K 345 VT.B(W)/O FP 653.3 SCHOLTES C 648 PT.4 X I K 342 MS.B(W)/I K 342 MS.B(X)/I C 615 .5 (W)F K 632 M.C(W)/F C 648 PT.3 X B K 341 E(W)/U C 649 PT XA U FB 22 AC.1 (WH) HB 22 AC.1 (WH) CP 648 MT.2 B CP 058 MT.2 B FP 650.2 SCHOLTES C 67S P2 X I C 649 PT.3 XA U K 345 E.B(X)/U K 341 E.B(W)/U CP 6V8 M (X) DE C 65S P2 X B C 61S M2 (W) T C 64S M2 (W) T K6M52(W)/F K6G52S(X)/R KP 648 MS (X)/DK (T) KP 958 MS (X)/DK (T) KP 648 MS (X)/DE (T) ST52X SC52VX SD52I SD52K K6T72S(X)/I K6T52S(W)/I K6T52S(X)/I K6G52(W)/U K6G32(X)/G K6G32(W)/G K6C32(W)/G K6C32(X)/G K6E32(W)/G K6E32(X)/G K6G52(W)/G K6G52(X)/G K3G12(W)/U K6E52(W)/EX K6G72(W)/EX CISFD 52.2 (ICE) K6T72S(W)/NL K6T72S(X)/NL K6E52(W)/GR FB 52 C.2 IX TD K3G52S(W)/I K3G52S(X)/I K3G12(X)/U K3G52S(W)/R K3T32(W)/O K6C320(W)/G K6C320(X)/G K6G520(W)/G K6G520(X)/G FB 52 C.2 (WH) KP 648 MS (X)/DE CP 648 MT.1 CP 758 MT.1 K3G52S(W)/AT KP 648 MS (X)/DK CP 058 MT.2 KP 958 MS (X)/DK KP 958 MS.B (X)/D FC 52.2 /V (AN) /HA - FC 52.2 /V IX /HA - CP65SP2 /HA - CP77SP2 /HA - CP97SE2 /HA - FC 52 C.1 /V IX /HA - KP9F92S(X)/DE KP6T72S(X)/DK A6TMH2F (W) IL A6TMH2F (X) IL I6TMH2AF(X)/IL , FO52(IX) 03255120000, C00052578
